Whitman Controls P117G-3H-C12L-DIS Stainless Steel Pressure Switch

Whitman Controls P117G-3H-C12L-DIS Stainless Steel Pressure Switch

[Condition]

Unit is used, in great condition, pulled from a working system. See photos, item comes as shown.

[Info on Unit]

Manufacturer: Whitman Controls

Model: P117G

Part Number: P117G-3H-C12L-DIS

Type: Miniature Pressure Switch

Sensor Code: 3H

Operating Pressure Range: 1.6–30 PSIG increasing

Decreasing Set Point Range: 0.8–28.5 PSIG

Maximum System Pressure: 30 PSIG

Set Point Repeatability: ±0.6 PSI

Output: SPDT

Electrical Connection: Wire Leads

Process Connection: 1/8-27 NPT Male

Maximum Electrical Rating: 5 A

Operating Temperature: -65°F to +225°F (-54°C to +107°C)

Sensor Element: Capsule

[Description]

The Whitman Controls P117G-3H-C12L-DIS is a compact stainless steel pressure switch designed for pressure monitoring and switching in OEM equipment, industrial machinery, pneumatic systems, and process-control applications. The 3H sensor configuration provides an increasing-pressure set point range of 1.6 to 30 PSIG with ±0.6 PSI repeatability and a maximum system pressure of 30 PSIG. This configuration uses an SPDT electrical output with wire leads and a 1/8-27 NPT male process connection. The P117G utilizes a capsule-type sensing element with stainless steel wetted components and supports operating temperatures from -65°F to +225°F. Its compact construction makes it suitable for installations where space is limited while still providing an adjustable mechanical pressure-switching function.
