Bruker BLA2X500 W1345067 Dual 500W RF Power Amplifier 6-365MHz [NMR Spectrometer]

Bruker BLA2X500 W1345067 Dual 500W RF Power Amplifier 6-365MHz [NMR Spectrometer]

[Condition]

Unit is used, in great condition, pulled from a working decommissioned Bruker NMR Spectrometer. See photos, item comes as shown.

[Info on Unit]

Manufacturer: Bruker BioSpin

Model: BLA2X500

Part Number: W1345067/00/2.00/0010

Type: Dual-Channel Broadband Linear RF Power Amplifier

Application: Nuclear Magnetic Resonance (NMR) Spectroscopy

Frequency Range: 6–365 MHz

Number of RF Channels: 2

Peak Output Power: 500 W Per Channel up to 300 MHz

Peak Output Power at 365 MHz: 400 W Minimum Per Channel

Continuous RF Output: 30 W Maximum Per Channel

Linear Output Power: 400 W Typical at 1 dB Compression

Linear Gain: 57 dB Typical

Gain Flatness: ±1 dB

Linearity: ±1 dB to 400 W

Amplifier Class: Class AB

Input/Output Impedance: 50 Ohms

Input VSWR: 1.3 Maximum

RF Rise Time: Less Than 100 ns

RF Fall Time: Less Than 50 ns

Blanking Delay: Less Than 2 µs Typical

Maximum Pulse Width: 60 ms at 500 W

Maximum Duty Cycle: 6% at 500 W

Maximum Continuous Duty Cycle: 100% at 30 W

AC Input Voltage: 230 VAC

AC Frequency: 50/60 Hz
